  Gun Drilling Machine



We are certified under
ISO 9001:2008












      Specifications
      Model
Drilling capacity of diameter
Drilling capacity of depth
Working table size
Controller
Spindle motor
Spindle speed
Number of spindles
X-axis travel
Y-axis travel
Z-axis travel
Table loading capacity

FW-2013
Standard: Ø3~25mm (Optional: Ø4~40mm)
Standard: 1500mm (Optional: 2000mm)
1200 x 2260mm
MITSUBISHI M64ASM
AC servo 7.5 kw
100~8000 rpm
1
2000mm
1300mm
Standard: 2000mm (Optional: 2500mm)
15000kgs




  Work Piece       Machining Video
